The XQM series variable frequency planetary ball mill is a versatile device for mixing, fine grinding, sample preparation, nanomaterial dispersion, new product development and small batch production of high-tech materials. It supports both dry and wet grinding methods, with the minimum particle size of ground products as low as 0.1 microns.
Equipped with a vacuum ball mill jar, the mill can grind samples under vacuum conditions, expanding its application range in geology, mining, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, environmental protection and other departments. Rotation speed, forward and reverse rotation time and total grinding time can be set according to process requirements.
Product Features
- Vacuum Jar Grinding Available: Equipped with a vacuum ball mill jar for grinding samples under vacuum conditions.
- Dry and Wet Grinding Methods: Supports grinding and mixing of materials with different particle sizes by both dry and wet methods.
- Variable Frequency Speed Control: Rotation speed, forward and reverse rotation time and total grinding time can be set according to process requirements.
- 0.1 Micron Fine Grinding: Minimum particle size of ground products can be as low as 0.1 microns.
- Four Jars Simultaneous Grinding: Four samples can be obtained at the same time in each experiment, improving laboratory efficiency.
- Quiet High-Speed Operation: CNC machined parts, integral cast planetary plate and special material precision gears ensure smooth and quiet operation at high speed.
Working Principle
The XQM series variable frequency planetary ball mill is equipped with four ball mill jars on the same turntable. When the turntable rotates, the ball mill jars revolve around the axis of the turntable and rotate around their own axis, making a planetary motion. The grinding balls in the jar collide with each other in high-speed motion, grinding and mixing the sample. The product can grind and mix materials with different particle sizes by both dry and wet methods, and the minimum particle size of the ground products can be as low as 0.1 microns.
Model Specifications
| Model |
Max. Jar Volume |
Voltage |
Power |
Machine Size (mm) |
Weight (kg) |
Rotational Speed (RPM) |
Revolution Speed (RPM) |
| YXQM-2 |
500 mL |
220V, 50Hz |
0.75 kW |
750x470x564 |
93 |
40-670 |
20-335 |
| YXQM-4 |
1000 mL |
220V, 50Hz |
0.75 kW |
750x470x564 |
93 |
40-670 |
20-335 |
| YXQM-6 |
1.5 L |
220V, 50Hz |
0.75 kW |
750x470x564 |
150 |
40-670 |
20-335 |
| YXQM-8 |
2 L |
220V, 50Hz |
1.5 kW |
900x600x640 |
150 |
40-670 |
20-335 |
| YXQM-10 |
2.5 L |
220V, 50Hz |
1.5 kW |
900x600x640 |
150 |
40-670 |
20-335 |
| YXQM-12 |
3 L |
220V, 50Hz |
1.5 kW |
900x600x640 |
150 |
40-670 |
20-335 |
| YXQM-20 |
5 L |
380V, 50Hz |
4 kW |
1200x750x920 |
330 |
40-670 |
20-335 |
| YXQM-40 |
10 L |
380V, 50Hz |
5.5 kW |
1400x850x1160 |
400 |
40-670 |
20-335 |
| YXQM-60 |
15 L |
380V, 50Hz |
7.5 kW |
1600x990x1250 |
900 |
40-670 |
20-335 |
| YXQM-100 |
25 L |
380V, 50Hz |
11 kW |
1750x1140x1330 |
1250 |
40-670 |
20-335 |
* Rotational and revolution speeds vary by model within the series range; exact values to be confirmed with our engineers when selecting a model.
Series Common Specifications
| Work Mode |
Two or four tanks work at the same time |
| Mill Mode |
Ball Mill |
| Speed Frequency |
Frequency conversion |
| Drive Mode |
Gear Drive |
| Material Capacity |
Two-thirds of the volume of the jar |
| Input Granularity |
Soil material ≤ 10 mm; other materials ≤ 3 mm |
| Output Granularity |
Up to 0.1 micron, depending on materials and grinding process |
| Grinding Jar Materials |
Agate, Zirconia, Carbide, PTFE, Stainless Steel, Nylon, Corundum, Polyurethane |
| Grinding Media |
Agate Ball, Zirconia Ball, Carbide Ball, Stainless Steel Ball, Alumina Ball, Polyurethane Coated Iron Ball, Steel Ball |
| Max. Continuous Operating Time |
3600 min |
Rotational and revolution speeds vary by model within the series range; exact values to be confirmed with our engineers when selecting a model.
Applications
The XQM variable frequency planetary ball mill is widely used in geology, mining, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, beauty, environmental protection and other departments for microparticle research sample preparation, mixing and fine grinding.
About Y&X Beijing Technology
Y&X Beijing Technology Co., Ltd., established in 2014 and headquartered in Beijing, China, is a professional enterprise integrating scientific research, design, new product development, production and manufacturing. The company specializes in the research and supply of mineral processing reagents and equipment, including both industrial and laboratory mineral processing equipment. Our products are successfully marketed in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia, Tanzania, Nigeria and other countries and regions. The enterprise has achieved ISO 9001 quality management system certification, ensuring product quality conforms to relevant national and enterprise technical standards.
Frequently Asked Questions
Q1: Can this mill grind under vacuum?
Yes. It is equipped with a vacuum ball mill jar that can be used to grind samples under vacuum conditions.
Q2: Does it support dry and wet grinding?
Yes. The mill can grind and mix materials with different particle sizes by both dry and wet methods.
Q3: Can rotation speed and grinding time be set?
Yes. Rotation speed, forward and reverse rotation time, and total grinding time can be set according to process requirements with variable frequency control.
Q4: How many samples can be ground at one time?
Four samples can be obtained at the same time in each experiment, as the mill is equipped with four grinding jars on one turntable.
Q5: What is the minimum particle size?
The minimum particle size of the ground products can be as low as 0.1 microns.
Q6: Can this machine be customized?
For different voltage requirements, jar configurations or other technical requirements, please confirm the specifications with the supplier before ordering.
